Print
Print Head/Consumables

Number of Nozzles: Total 1,472 nozzles

Ink Bottles (Type/Colours)GI-790: (Pigment Ink/Black), (Dye-based Ink/Cyan, Magenta, Yellow)

Print Heads: BH-7, CH-7 (Availability may vary by country)

Maximum Print Resolution: 4,800 (Horizontal)^*1 x 1,200 (Vertical) dpi

Print Speed^*2 (Approx.)
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions

Document (ESAT/Simplex)^*3: 8.8 / 5 ipm (Mono/Colour)

Document (FPOT Ready/Simplex)^*4: 11 / 17 sec (Mono/Colour)

Photo (4 x 6") (PP-201/Borderless)^*5: 60 sec

Print Width: Bordered: Up to 203.2 mm (8"), Borderless: Up to 216 mm (8.5")

Recommended Printing Area: Top margin: 31.2 mm, Bottom margin: 32.5 mm

Scan^*6
Scanner Type: Flatbed (ADF/Platen)

Scanner Technology: Contact Image Sensor (CIS)

Optical Resolution^*7: 600 x 1,200 dpi

Scanning Bit Depth (Input/Output)

Greyscale: 16 bit / 8 bit

Colour: 48 bit / 24 bit (RGB each 16 bit / 8 bit)

Maximum Document Size

Flatbed: A4, LTR (216 x 297 mm)ADFA4, LTR, LGL

Copy
Copy Speed^*8 (Approx.):
Click here for summary report
Click here for Document Print and Copy Speed Measurement Conditions

Document (Colour): (sFCOT/Simplex)/(sESAT/Simplex): 24 sec / 3.5 ipm

Document (ADF): Mono/Colour (ESAT/Simplex): 8 / 2.5 ipm

Maximum Copies: 99 pages

Maximum Document Size

Flatbed: A4, LTR

ADF: A4, LTR, LGL

Fax
Type: Desktop Transceiver (Super G3/Colour Communication)

Transmission^*9

Mono: 3 sec

Colour: 1 min

Modem Speed: Max. 33.6 kbps (Automatic fall back)

Compression

Mono: MH, MR, MMR

Colour: JPEG

Gradation

Mono: 256 levels

Colour: 24-bit Full Colour (RGB each 8-bit)

ECM (Error Correction Mode): ITU-T T.30 compatible

Automatic Dialling

Group Dialling: Max. 19 locations

Transmission/Reception Memory^*10: Approx. 50 pages

PC Fax
Type: Windows, macOS

Mono/Colour: B/W Transmission only

Paper Handling
Print Margin

Borderless Printing^*11: Top/Bottom/Left/Right margin: 0 mm

Bordered Printing: LTR, LGL: Top margin: 3 mm, Bottom margin: 5 mm, Left margin: 6.4 mm, Right margin: 6.3 mm
Others: Top margin: 3 mm, Bottom margin: 5 mm, Left/Right margin: 3.4 mm

Supported Media

Rear Tray: Plain Paper (64 - 105 g/m²), High Resolution Paper (HR-101N), Photo Paper Plus Glossy II (PP-201, PP-208) , Photo Paper Pro Luster (LU-101), Photo Paper Plus Semi-Gloss (SG-201), Matte Photo Paper (MP-101), Envelope

Paper Size

Rear Tray :A4, A5, B5, LTR, LGL, Envelope (COM10, DL), 4 x 6", 5 x 7", 8 x 10", Square (127 x 127 mm), Business Card
[Custom Size]: Width: 55 - 215.9 mm, Length: 89 - 676 mm, ^*F4 is possible via custom size settings.

Borderless Printing^*11: A4, LTR, 4 x 6", 5 x 7", 8 x 10", Square (127 x 127 mm), Business Card

Maximum Capacity

Rear Tray: Plain Paper (A4, A5, B5, LTR, 64 g/m²): 100, High Resolution Paper (HR,101N): 80, Photo Paper Plus Glossy II (PP-201, PP-208, 4 x 6"): 20, Photo Paper Plus Semi-Gloss (SG-201, 4 x 6"): 10, Matte Photo Paper (MP-101, 4 x 6"): 20, Envelope (COM10, DL): 10

Auto Document Feeder: Plain Paper (A4, LTR): 20, Plain Paper (LGL): 5

Paper Weight

Rear Tray: Plain Paper: 64 - 105 g/m², Canon Paper: Approx. 275 g/m² (Max.), (Photo Paper Plus Glossy II, PP-201)

Network
Protocol: TCP/IP

Wireless LAN

Type: IEEE802.11b/g/n, 2.4 GHz, Supported Channels: 1 - 13, (TW/HK: Supported Channels: 1 - 11 only)

Security: WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES)

Direct Connection (Wireless LAN): Available (AP Mode only)

Printing Solutions
Canon Printing Apps

Mobile: Canon PRINT, Easy-PhotoPrint Editor

Others: PosterArtist Lite, PosterArtist (Web)

Mobile/Cloud Printing Solutions: AirPrint^®, Mopria^® Print Service, Cloud Integration Service (via smartphone/tablet)

System Requirements
OS System Compatibility^*12 :Windows 10 / 8.1 / 7 SP1, macOS 10.12 or later, ChromeOS

General Specifications
Operation Panel

Display: 2-Line LCD

Interface: USB 2.0

Operating Environment^*13

Temperature: 5 - 35°C

Humidity: 10 - 90% RH (no dew condensation)

Recommended Environment^*14

Temperature: 15 - 30°C

Humidity: 10 - 80% RH (no dew condensation)

Storage Environment

Temperature: 0 - 40°C

Humidity: 5 - 95% RH (no dew condensation)

Quiet Mode: Available

Acoustic Noise^*15

Plain Paper (A4, Mono): 53.5 dB(A)

Power Requirements: AC 100 - 240 V, 50/60 Hz

Power Consumption (Approx.)

OFF: 0.2 W

Standby: 0.9 W

Operation^*16 :10 W

Dimensions (W x D x H)

Factory Configuration: 445 x 330 x 197 mm

Output/ADF Trays Extended: 445 x 526 x 249 mm

Weight: 7.3 kg
